What are the benefits of Swiss type machining parts?

The CNC market is undergoing tremendous growth. One of the biggest factors is the proliferation of new types of machining, that is, Swiss type machining parts. There is an entire segment of the industry known as Swiss type machining parts. A number of manufacturers are exploring the benefits and looking to use Swiss type machining parts to get more efficiency and cut costs.



  • What are the benefits of Swiss type machining parts?

  • How to correct deflection of Swiss type machining parts?

  • What are the applications of Swiss type machining parts?



1. What are the benefits of Swiss type machining parts?

In order to fully appreciate the benefits of Swiss type machining parts, it is necessary to explore the nuances of the processes that Swiss type machining parts entails. The benefits rely largely on the designs of the machining equipment.

There are a lot of Swiss type machining tools on the market, all of which have some major benefits. One of the best examples is the Swiss style machining lathe. There are some differences between these types of lathes that may seem subtle to the average layperson. However, these differences are significant in actual machining applications. One of the biggest differences is that the holding mechanism is not exposed to the bed or the tooling.

Better support for all stock material: When you are turning any material with Swiss type machining, it is important to make sure that it is adequately supported. You are going to get a poor and likely uneven cut if the material jostles around. This is probably the biggest benefit of Swiss type machining parts, providing much better support than traditional machining. You should have fewer defective parts due to the reduced risk of the support material moving.

Superior tolerance: Swiss type machining parts take advantage of the process known as guide brushing. The biggest benefit is enhanced rigidity, leading to a higher tolerance level.

Swiss type machining parts have ability to work with smaller parts: There are a number of scenarios where machinist will want to work with smaller parts. Unfortunately, this is not feasible with standard machining. They would need to use more expensive machining processes, such as making laser cuts. Swiss type machining parts are able to handle very small parts, which means that Swiss type machining parts are often the most affordable option to affectively make cuts. Swiss type machining parts can be more cost-effective with dealing with smaller materials and can make it easier to make more precise cuts.



2. How to correct deflection of Swiss type machining parts?

The purpose of supporting the workpiece with the guide bushing is to maintain precision throughout the Swiss type machining parts of the workpiece.

A physical object subjected to a force will deflect. On a conventional CNC machining parts, if the cutting forces cause too great a deflection the accuracy of the cut will suffer. A widely accepted rule of thumb is that on a conventional CNC machining parts when you turn parts with a length-to-diameter ratio of greater than 3:1, you should use a tailstock to prevent excessive deflection. For a ratio greater than 6:1, you would use a steady rest or follow rest to support the middle of the part.

If you hold a workpiece securely at one end and push sideways on the unsupported end, the workpiece bends a certain amount. Push with the same force on a longer workpiece and it will bend more. In fact, the deflection for a given force increases as the cube of distance from the support to the force is twice as long with eight times the deflection.

With Swiss type machining parts, the guide bushing supports the workpiece so close to the tools that the deflection due to the cutting forces is essentially zero. As a result, you can take heavy cuts and still maintain precise dimensions on the Swiss type machining parts.



3. What are the applications of Swiss type machining parts?

There are a couple of ways that Swiss type machining parts can work. Manufacturers can copy the processes that Swiss companies use to produce products. They can also find new applications for Swiss type machining parts, such as the Swiss lathe.

There are a number of industries where Swiss type machining parts is becoming more important. The durable goods industry is a prime example. In2020, the durable goods industry was worth $20 billion, increasing 8 percent over the past year. More recent reports show this figure is even higher. They are discovering that Swiss type machining parts are highly beneficial, as they look for innovative ways to trim costs and improve output.

Other industries are relying on Swiss type machining parts as well. The electronics and medical industries are becoming more reliant on Swiss type machining parts and other swiss machining tools.

Current Swiss type machining parts are prevalent in the automotive, IT, and consumer electronic industries. High-quality designer Swiss watch production initially developed and utilized the Swiss type machining parts, and this accuracy and delicacy is prized in many facilities. Due to quick production times and low variable costs, as well as largely unsupervised production methods of Swiss type machining parts, Swiss type machining parts can produce a large number of small, precision parts relatively quickly at low cost. Because Swiss type machining parts can handle both exotic and common metals of varying strengths and composition, they are widely applicable and feature as integral processes in many different industries.




Learn more something about Swiss type machining parts can know the benefits of Swiss type machining parts and the applications of Swiss type machining parts. If you want to buy high-quality Swiss type machining parts with reasonable price, JST Industry can help you to open up a further and larger market, it is wise to choose us as your business partner, whether you need any plastic prototyping or customized parts. We also provide other Swiss type machining parts and we appreciate that you contact with us.
